FRAME: CRMO TRIANGLE AND CHAINSTAYS

• TOP TUBE
• 20.75″
• HEADTUBE
• Integrated
• BB SHELL
• MID
• DROP OUTS
• 14mm
• BRAKE MOUNTING
• Thread-on 990
• SEAT CLAMP
• Integrated

FORK

• STEERER TUBE
• 1 Piece CNC CrMo/24MM Compression Bolt
• LEGS
• CrMo Tapered
• DROP OUTS
• CrMo 3/8″

STEERING

• HANDLEBAR
• 4 Piece Full CrMo 8.85” X 28.5”
• STEM
• Front Load
• GRIPS
• BENNY
• HEADSET
• Integrated 45°/45° Sealed 41.8MM

BRAKING

• REAR BRAKE
• Alloy 990 U-Brake, Soft Compound Pads
• BRAKE LEVER
• Alloy Hinged
• BRAKE CABLE
• Odyssey Slic

SEATING

• SEAT
• BARSTOOL Textured Pivotal
• SEAT POST
• 200mm Alloy Pivotal

DRIVETRAIN

• FRONT/REAR
• 25/9
• CRANKS
• Indented CrMo 170mm 48 Spline
• BOTTOM BRACKET
• Sealed Bearing MID
• SPROCKET
• Aluminum Key CNC 25T
• PEDALS
• MAC PC
• CHAIN
• KMC Z510HX

WHEELS

• FRONT HUB
• Alloy Sealed 3/8″ Female Axle
• FRONT RIM
• Revenge OHM Double Wall 36H
• FRONT TIRE
• 2.3 FAF 110 PSI
• REAR HUB
• Alloy Free Coaster
• REAR RIM
• Revenge OHM Double Wall 36H
• REAR TIRE
• 2.3 FAF 110 PSI
• SPOKES
• 14G
• NIPPLES
• Brass
• HUB GUARD
• N/A

EXTRA

• PEGS
• 100mm (x2)
• WEIGHT
• 25.50 LBS / 11.56 KG
• COLOR(S)
• Matte Purple

GEOMETRY

• HEAD ANGLE
• 75.5°
• SEAT ANGLE
• 69°
• CHAINSTAY
• 13.11″
• BB HEIGHT
• 11.6″
• STANDOVER
• 8.25″
