Redline Pit Boss BMX Bike-16"-Red/Gray

Redline
Sold Out

About This Product: Redline Pit Boss BMX Bike-16"-Red/Gray

PRODUCT DETAILS

Race the BMX track, ride some trails or cruise the neighborhood. Light alloy frame and ideal geometry make the Pitboss the go anywhere 16” bike for every little ripper.

KEY FEATURES

6061 T6 Alloy Frame, Integrated HT, Euro BB
Redline Microline 3pc, Cranks
Redline Microline Seat/Post combo
Kenda Kontact Tires


 FRAME SPECS:
Toptube Length: 14.4"
Head Angle: 72
Seat Angle: 72
BB Height: 9.7"
Chainstay: 11.9"


RECOMMENDED RIDER HEIGHT:  Under 4"



Frame 6061 T6 Alloy Formed Tubing, Machined BB, Integrated HT, Euro BB
Fork RL Chromo 1" steer tube, tapered legs
Colors Gloss Red /White
Headset Integrated 1" Headset
Stem RL Mini Aluminum HollowPoint 40mm
Handlebar RL Aluminum 5.5" 10˚ Back x 2˚ Up
Grips RL Mini Hex Grips
Seat RL Microline Seat/Post Combo 22.2 Aluminum post
Seat Post RL Microline Seat/Post Combo 22.2 Aluminum post
Seat Post Clamp Redline Proline Aluminum 25.4mm
Rims RL Spec 28h Aluminum
Front Hub Redline Aluminum
Rear Hub Redline Aluminum Flip-Flop
Spokes Black 14g
Tires Kenda Kontact 16 x 1.75 Tires
Crankset RL Microline 3pc 140mm,Cranks
Bottom Bracket Sealed Euro BB
Pedals Redline Jr Aluminum Platform / Chromo Spindle
Brake Tektro 926AL Linear
Brake Lever Tektro
Chain KMC Z33
Gearing 36/16
Extras Redline Chain Tensioners


NOTE: As with any complete bike, J&R Bicycles recommends that you have a professional bicycle store build your bike. Bikes ordered through mail-order come partially assembled and need to be inspected and assembled by a bicycle mechanic. Failure to do so may void the manufacture's warranty. Manufacture's warranties differ for every brand. You can check the brand's website for warranty information.

Additional Information

Barcode 030932
Special Shipping Group N/A

Complete Bike specifications and components may differ from photos and description. Manufacturers reserve the right to make changes and/or substitutions due to parts availability, production requirements and ongoing development decisions.

Redline Race Bike Size Charts

Redline Race Bike Size Charts
Size Rider's Height
: Micro : 4'4" and under
: Mini : 4'2" - 4'6"
: Junior : 4'6" - 5'1"
: Pitboss : 4'2" - 5'1"
: Expert : 5'0" - 5'4"
: Expert XL : 5'2" - 5'6"
: Pro : 5'3" - 5'8"
: Pro XL : 5'7" - 6'0"
: Pro XXL : 6'0" and over
: Pro 24 : 5'7" and over
