About This Product: Redline Recon Bike-Ano Grey

PRODUCT DETAILS

Idealized geometry, fully sealed rear hub, micro gearing, 2.30 tires and big box bars are details that make the Redlne 2018 Recon perfect for the Intermediate shredder.
Frame Hi-Ten Machined Head tube, Device type 5mm dropouts
Fork RL Monster Tapered leg fork
Colors Anno Grey, Blue Gray
Headset Threadless 1 1/8
Stem Hi-Rise Top Load, 50mm
Handlebar Hi-Ten 8.25 Rise/ 28" Wide 12¡ Back, 1¡ Up
Grips Monster 151 Flangeless w/Plugs
Seat Monster Padded Combo Saddle w/ 25.4 Post
Seat Post 25.4mm post
Seat Post Clamp Integrated Bolt
Rims RL spec 36h Alloy
Front Hub RL Spec 3/8" Heat Treated Axle
Rear Hub Aluminum, Fully Sealed, Chromo 14mm axle
Spokes Black
Tires 20 x 2.30"" Park/Street Tires
Crankset 100% chromo 170mm 3pc tubular cranks
Bottom Bracket American
Pedals RL Spec 9/16" Ultra Low Profile Resin Platform
Brake Tektro 340 Rear U-Brake
Brake Lever Tektro
Chain Z410
Gearing 25/9
Extras
Bicycle Weight 26 lbs 14 oz

Top Tube 20.4"
Head Angle 74˚
Seat Angle 70˚
BB Height 20.4"
Chainstay 13.7"


Additional Information

Barcode 148103
Special Shipping Group No

Complete Bike specifications and components may differ from photos and description. Manufacturers reserve the right to make changes and/or substitutions due to parts availability, production requirements and ongoing development decisions.

Redline Race Bike Size Charts

Redline Race Bike Size Charts
Size Rider's Height
: Micro : 4'4" and under
: Mini : 4'2" - 4'6"
: Junior : 4'6" - 5'1"
: Pitboss : 4'2" - 5'1"
: Expert : 5'0" - 5'4"
: Expert XL : 5'2" - 5'6"
: Pro : 5'3" - 5'8"
: Pro XL : 5'7" - 6'0"
: Pro XXL : 6'0" and over
: Pro 24 : 5'7" and over

Need Some help Choosing a BMX Bike?

Selecting the right size BMX bike is vital for a smooth and delightful ride. At J&R Bicycles, we understand the BMX world inside out because we're passionate riders ourselves. Just reach out to us, and we'll be more than happy to assist you on your journey to finding the perfect BMX bike.

Curious to learn more? We've compiled a comprehensive BMX buyer's guide to demystify the process. Read on, and together, we'll uncover the BMX bike that perfectly matches your riding style and preferences.
